• Autotrac active transfer case
• 4-wheel drive
• HD 600-CCA battery
• 130-amp alternator
• 7-wire trailering harness
• (2) front recovery hooks
• 7200# GVWR (3600 front/4000 rear), springs (3600 front/4000 rear), axles (3925 front/4000 rear)
• Independent short & long arm front suspension w/torsion bars
• Multi-link coil spring rear suspension
• Front stabilizer bar
• P245/75R16E all-season SBR BSW tires
• Full-size spare tire w/lockable winch-type carrier mounted under rear frame
• 16" silver-painted steel wheels w/argent center cap
• Speed-sensitive pwr recirculating ball steering
• Pwr 4-wheel disc brakes
• 4-wheel anti-lock braking system
• 32.5 gallon fuel tank
• Single 2-sided key

• Chrome front bumper w/matte black top pad
• Chrome rear bumper w/matte black step pad
• Dark argent air dam
• Matte black molded grille w/argent center bar
• Dual composite halogen headlamps
• Automatic headlamp control
• Daytime running lights
• Dual black foldaway manual mirrors
• Solar-Ray tinted glass
• Intermittent windshield wipers w/washers
• Matte black door handles
• Rear cargo doors

• Vinyl reclining 40/20/40 split front bench seat
• Black vinyl floor covering
• Tilt steering column
• Simulated leather steering wheel
• Warning tones-inc: key-in-ignition, safety belt, headlamps, turn signal
• Programmable pwr door locks
• Cargo area door lock switch
• Passlock theft deterrent system
• ETR AM/FM stereo-inc: seek-scan, digital clock
• (4) speakers (2000)
• Dual front/dual rear cupholders
• Dual front/single rear cargo area covered pwr outlets
• Manual day/night rearview mirror
• Full color-keyed cloth headliner
• Dual cloth sunshades w/LH storage clip, passenger vanity mirror
• Front passenger/dual rear seat assist handles
• Lights-inc: dome w/delayed entry feature, ashtray, glove box, underhood

• 4-wheel anti-lock braking system
• Driver & front passenger front airbags
• Driver & front passenger side-impact airbags
• Lap/shoulder safety belts at all outboard seat positions w/all-belts-to-seat
• Lap safety belt at all inboard seat positions
• Daytime running lights

4-SPEED ELECTRONICALLY-CONTROLLED AUTOMATIC TRANSMISSION W/OD

• tow/haul mode (STD)

SMOOTH RIDE SUSPENSION

• (STD)

REAR CARGO DOORS

• (STD)

7200# GVWR

• (3600 front/4000 rear)
• springs (3600 front/4000 rear)
• axles (3925 front/ 4000 rear) (STD)

(5) P245/75R16E ALL-SEASON SBR BSW TIRES

• (STD)

40/20/40 SPLIT FRONT BENCH SEAT

• (STD)

5.3L (325) SFI V8 (VORTEC) ENGINE

• (STD)

CLIMATE PKG

• front air cond
• deep tinted glass
• rear defogger
• cruise control

BASE PREFERRED EQUIPMENT GROUP

• base vehicle only

VINYL SEAT TRIM

• (STD)

• 4-SPEED ELECTRONICALLY-CONTROLLED AUTOMATIC TRANSMISSION W/OD -inc: tow/haul mode (STD)
• SMOOTH RIDE SUSPENSION (STD)
• REAR CARGO DOORS (STD)
• 7200# GVWR (3600 front/4000 rear) springs (3600 front/4000 rear) axles (3925 front/ 4000 rear) (STD)
• SECOND ROW 60/40 SPLIT BENCH SEAT
• (5) P245/75R16E ALL-SEASON SBR BSW TIRES (STD)
• 3.73 AXLE RATIO
• 40/20/40 SPLIT FRONT BENCH SEAT (STD)
• LOCKING REAR DIFFERENTIAL
• 5.3L (325) SFI V8 (VORTEC) ENGINE (STD)
• CLIMATE PKG -inc: front air cond deep tinted glass rear defogger cruise control
• BASE PREFERRED EQUIPMENT GROUP -inc: base vehicle only
• VINYL SEAT TRIM (STD)
• Four Wheel Drive
• Tow Hooks
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Steel Wheels
• Power Steering
• 4-Wheel Disc Brakes
• ABS
• Automatic Headlights
• Daytime Running Lights
• Intermittent Wipers
• Vinyl Seats
• Split Bench Seat
• Adjustable Steering Wheel
• Power Door Locks
• Immobilizer
• AM/FM Stereo
• Power Outlet
• ABS
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Daytime Running Lights

• Vehicle
• Rear Door Type: Cargo Doors
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 16
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 130
• Cooling System
• Total Cooling System Capacity (qts): 13.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2736
• Curb Weight - Rear (lbs): 2387
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 13,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 600
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 8600
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: Multi-Link Coil
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 32
• Stabilizer Bar Diameter - Front (in): 1.18
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 13.0 x 1.18
• Tires
• Front Tire Order Code: QNK
• Rear Tire Order Code: QNK
• Spare Tire Order Code: QNK
• Front Tire Size: P245/75R16
• Rear Tire Size: P245/75R16
• Spare Tire Size: P245/75R16
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Speed-Sensitive Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 12.7
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 42.3
• Turning Diameter - Wall to Wall (ft): 46.0
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 32.5
• Fuel Tank Location: Behind Rear Axle
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/rear bumper (in): 219.3
• Width, Max w/o mirrors (in): 78.8
• Height, Overall (in): 75.4
• Overhang, Front (in): 37.0
• Overhang, Rear w/bumper (in): 52.3
• Ground to Top of Load Floor (in): 31.0
• Ground Clearance, Front (in): 9.8
• Ground Clearance, Rear (in): 8.4
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 104.6
• Cargo Area Length @ Floor to Seat 2 (in): 69.6
• Cargo Area Width @ Beltline (in): 49.2
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 40.5
• Cargo Volume to Seat 1 (ft³): 138.4
• Cargo Volume to Seat 2 (ft³): 90.0
• Interior Dimensions
• Passenger Capacity: 6
• Passenger Capacity: 3
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 61.6
• Summary
• Vehicle Name: Chevrolet Suburban
• Body Style: 4 Door 1500
• Body Code: ZW9
